Products Introduction
The TC series ceramic vacuum filter represents a cutting-edge solution for efficient solid-liquid separation in various industrial applications, particularly in the mining sector. Utilizing advanced vacuum technology, this filter employs ceramic plates made from durable corundum, renowned for its high-temperature resistance and longevity.
Key Features and Benefits:
Efficient Filtration: The ceramic plates are engineered with tiny holes that selectively allow liquid to pass while effectively blocking air and solid particles. This ensures a high-quality separation process, resulting in a consistent and dry cake formation.
Durability and Longevity: Constructed from corundum, the plates are designed to withstand harsh operating conditions, providing a long service life and reducing the need for frequent replacements.
High Efficiency: The TC series excels in dewatering applications, making it ideal for mining processes involving various materials, including nonferrous and ferrous metals, less-common metals, and electrolysis residue oxides.
Cost-Effective Solution: The filter offers low installation and operating costs, making it an economically attractive option for mining operations looking to improve their filtration processes without significant capital investment.
Versatile Applications: Beyond mining, this ceramic filter is effective for filtering chemical slag and other industrial materials, contributing to environmental protection efforts by managing waste efficiently.
Fine Material Handling: Capable of processing materials with a fineness of -200 to -450 meshes, the TC series is adept at handling very fine substances, ensuring versatility in various operational contexts.
Safety: The design prioritizes safety, minimizing risks associated with high-pressure operations and hazardous materials.
Product Application
Our TC series ceramic vacuum filter is engineered for diverse applications, particularly excelling in the mining and chemical processing industries. Its reliable performance and adaptability make it a valuable asset for any operation requiring efficient solid-liquid separation.
Key Applications:
Mining Industry
Separation of Ores and Minerals: Ideal for the extraction of various ores, including copper, zinc, lead, and rare earth elements. The filter effectively separates valuable minerals from their tailings, ensuring optimal recovery rates.
Chemical Processing
Environmental Protection
Material Specifications:
The TC series ceramic vacuum filter is an innovative and dependable solution designed to meet the rigorous demands of the mining industry. Its versatility extends to various sectors that require efficient solid-liquid separation, making it an essential tool for improving productivity and promoting sustainability in industrial processes.
Product Specifications
| Model area(m2) | Filter disc( circle) | Filter plate(pc) | Tank volume(m3) | Installed power(kw) | Operate power(kw) | Main engine(L*W*H)(M) |
| TC-1 | 1 | 12 | 2 | 4.5 | 4.3 | 1.2*1.5*1.4 |
| TC-4 | 2 | 24 | 1 | 6 | 5.8 | 1.6*1.0*2.1 |
| TC-6 | 2 | 36 | 1.2 | 8 | 7.5 | 3.0*2.2*2.1 |
| TC-9 | 3 | 36 | 1.7 | 9 | 8.5 | 3.0*2.8*2.6 |
| TC-12 | 4 | 48 | 2.2 | 13 | 12.5 | 3.6*2.8*2.6 |
| TC-15 | 5 | 60 | 3.7 | 13 | 12.5 | 3.8*2.8*2.6 |
| TC-18 | 6 | 72 | 3.7 | 15 | 14.5 | 4.1*2.9*2.6 |
| TC-21 | 7 | 84 | 4.8 | 17 | 16.5 | 4.6*2.9*2.6 |
| TC-24 | 8 | 96 | 5.5 | 17.5 | 16.5 | 4.6*2.9*2.6 |
| TC-27 | 9 | 108 | 6 | 17.5 | 16.5 | 5.2*2.9*2.6 |
| TC-30 | 10 | 120 | 6.7 | 21 | 20.5 | 5.5*2.9*2.6 |
| TC-36 | 12 | 144 | 8 | 33 | 32 | 6.0*2.9*2.6 |
| TC-45 | 15 | 180 | 10 | 33 | 32 | 6.6*2.9*2.6 |
| TC-60 | 15 | 180 | 12.5 | 47 | 46.5 | 6.7*3.3*3.0 |
| TC-80 | 20 | 240 | 164 | 53 | 52.5 | 8.2*3.3*3.0 |
| TC-102 | 17 | 204 | 185 | 71 | 70.5 | 7.9*3.6*3.3 |
| TC-120 | 20 | 240 | 20 | 80 | 78.5 | 8.7*3.6*3.3 |
| TC-150 | 25 | 360 | 24 | 92 | 91 | 9.2*3.6*3.3 |
(1) The Microvac operates at a vacuum level of 0.09 to 0.098MPa, resulting in a low moisture content of the cake.
(2) The filtrate has a solid content of less than 50ppm, making it suitable for recycling within the system.
(3) The Microvac achieves energy savings of up to 90%, with low energy consumption and operating costs.
(4) A filter cake cleaning system is included, specifically designed for materials that require washing.
(5) The integration of PLC and computer technology allows for automatic valve control, greatly reducing the need for manual labor.
(6) The Microvac's compact design requires minimal floor space and is easy to maintain.
(7) An advanced drainage system ensures that the Microvac can be used in any operating conditions.
