Industrial HVPF Vertical Automatic Filter Press

HVPF vertical automatic press filter is the most advanced filter that the world has ever get. Vacuum has a limit, but Pressure not. HVPF vertical automatic press filter use air or water to form a huge pressure difference on both sides of filter cloth to achieve very efficient separation of solid and liquid.

Quantity:
  • HVPF Filter Press
  • Toncin

Tower Vertical Press Filter




Product Introduction:


HVPF vertical automatic press filter is the most advanced filter that the world has ever get. Vacuum has a limit, but Pressure not. HVPF vertical automatic press filter use air or water to form a huge pressure difference on both sides of filter cloth to achieve very efficient separation of solid and liquid. As filter plate is closed, slurry is pumped into filter chamber through slurry pipes. Part of filtrate then enter the filtrate chamber through filter cloth because of gravity. Then high pressure water force rubber diaphragm to extrude filtrate from filter cake. When these process is finished, the driver run filter clothes and filter cakes is discharged from both sides of filter cloth.

Tower Vertical Press Filter

Product Application:


HVPF vertical automatic press filter can be applied in mining, metallurgy, chemical industry, pharmacy and food industries. It is a kind of high capacity, energy-saving, automatic solid-liquid separation machine.

Tower Vertical Press Filter

Supply Range and Requirements on Local Installation:


  1. (1) It consists of host, hydraulic station, water station, cleaning system and control system.

  2. (2) This machine must be installed on solid flat reinforced concrete, or steel rack. Consult foundation size and related dimension to installation sketch map and foundation chart. The depth of groundwork is determined by customers according to real conditions. Host should be suspended by professional technicians, avoid the equipment from impacting or scratching. Utilize grad enter to adjust the host during installation, then install other equipments during fastening the host.

  3. (3) Air supply: granule less than 5 um, pressure 0.5-0.6MPa, Air Volume: take assemble chart as reference

  4. (4) Water supply: max. solid contents 5ppm, solid granule less than 50um, pressure 3.5-6bar, take assemble chart as reference for supply volume

  5. (5)Power supply: 3 phase/380V±5%, single phase/220V±5%,50Hz

  6. (6)Working Environment: working environment requirements for this machine , not freeze.



Product Specifications:


Model



Filtrating Area(m2)

Overall Dimension

m (L×W×H)

Filtrating Plate Quantity

Volume(m3)
(H=45mm)

Weight

(T)

Hydraulic power

(KW)

Filter plate specification

(mm)

Width of filter cloth

HVPF-1

1

2.5×1.5×2.0

2

0.05

8

7.5

1000*550

0.7

HVPF-2

2

2.5×1.5×2.2

4

0.09

9

7.5

HVPF-3

3

3.5×2.5×2.2

2

0.16

14

11

1750*900

1.05

HVPF-4

4

3.5×2.5×2.3

4

0.27

15

11

HVPF-9

9

3.5×2.5×2.5

6

0.41

16

11

HVPF-12

12

3.5×2.5×2.7

8

0.54

17

11

HVPF-15

15

3.5×2.5×2.9

10

0.68

18

11

HVPF-18

18

3.5×2.5×3.1

12

0.81

19

11

HVPF-21

21

3.5×2.5×3.3

14

0.95

21

11

HVPF-24

24

3.5×2.5×3.4

16

1.08

22

11

HVPF-27

27

3.5×2.5×3.6

18

1.22

23

11

HVPF-15

15

5.1×3.7×3.3

6

0.68

37

22

2500*1020

1.15

HVPF-20

20

5.1×3.7×3.6

8

0.9

39

22

HVPF-25

25

5.1×3.7×3.9

10

1.13

42

22

HVPF-30

30

5.1×3.7×4.2

12

1.35

43

22

HVPF-35

35

5.1×3.7×4.5

14

1.58

44

22

HVPF-40

40

5.1×3.7×4.8

16

1.8

45

22

HVPF-45

45

5.1×3.7×5.1

18

2.03

46

22

HVPF-50

50

5.1×3.7×5.4

20

2.25

48

22

HVPF-60

60

6.9×4.5×5.4

10

2.7

97

37

4010*1500

1.7

HVPF-72

72

6.9×4.5×5.8

12

3.24

100

37

HVPF-84

84

6.9×4.5×6.2

14

3.78

104

37

HVPF-96

96

6.9×4.5×6.5

16

4.32

110

37

HVPF-108

108

6.9×4.5×6.9

18

4.86

112

37

HVPF-120

120

6.9×4.5×7.2

20

5.4

118

37

HVPF-132

132

6.9×4.5×7.6

22

5.94

120

37

HVPF-144

144

6.9×4.5×7.9

24

6.48

123

37

HVPF-156

156

6.9×4.5×8.3

26

7.02

126

37

HVPF-168

168

6.9×4.5×8.6

28

7.56

130

37

HVPF-144

144

9.2×5.5×6.8

18

6.48

142

67

6020*1500

1.7

HVPF-162

162

9.2×5.5×7.2

18

7.29

147

67

HVPF-180

180

9.2×5.5×7.5

20

8.1

150

67

HVPF-198

198

9.2×5.5×7.8

22

8.91

160

67

HVPF-216

216

9.2×5.5×8.2

24

9.72

166

67

HVPF-234

234

9.2×5.5×8.5

26

10.53

172

67

HVPF-252

252

9.2×5.5×8.8

28

11.34

180

67

HVPF-270

270

9.2×5.5×9.2

30

12.15

190

67




 Working Process:

Tower Vertical Press Filter

  1. (1) Filtering stage: when the filter plate closed, the slurry is pumped into filter chamber through slurry pipe. The filtrate enter into the filtrate chamber through filter cloth, and get into filtrate manifold through filtrate tube, meanwhile, the filter cake is formed in the filter chamber.

  2. (2) Extrusion: the high pressure water enters into membrane through the tube and make the membrane extrudes towards filter cake to make the filtrate of the filter cake extrude out.

  3. (3) Cake washing: the washing water is pumped into filter chamber by slurry pipe, after washing the cake and through cloth flow into the discharge pipes.

  4. (4) Air drying: the air flow with water go through the filter cake, which can reduce the moisture of filter cake to the maximum and empty the filtrate chamber at the same time.

  5. (5)Filter cake discharge: when the drying process finished, the driving parts drive the filter cloth to run and the filter cake discharges from both sides of filter cloth.

  6.

Main Features:



Tower Vertical Press Filter


  1. (1) The structure of filter plate adopts guide device to make sure the smoothly running.

  2. (2) It can continuously automatically realize the operation in the process of filtering, extrusion, washing, drying, discharging and filter cloth regeneration.

  3. (3) The filter pressure can reach 2.0 Mpa. Especially have good effect on various sticky tiny materials and low moisture of filter cake.

  4. (4)the key point of this type of equipment is no matter how much pressure it can get but safety. Hydraulic pressure system is adopted just to make sure every plate locks well. Every nozzle and diaphragm are designed and inspected very carefully to keep the equipment safe when high pressure water gets into chambers.

  5. (5) The equipment adopts PLC + touch screen + automatic valves, and labor input is lower..

  6. (6) Compact structure covers less floor area



Product Details:



Tower Vertical Press Filter






Service Support



  • Whole Technological Design

    Toncin determines reasonable plans and selections by conducting more systematic laboratory tests, semi-industrialization tests and theoretical analysis calculations and adopting appropriate methods in light of the actual problems faced by customers. And it determines specific parameters through laboratory tests and semi-industrial tests.


  • Project Construction

    Toncin can provide customers with integrated project services for its perfect project management system and experienced high-quality team and can also provide customers with its best services in achieving the ultimate project goal by carrying out the management work on the project quality, schedule, safety, cost, procurement, information files, organization and coordination etc. according to customer’s contractual documents. Toncin contracts the design, procurement, construction and trials etc. for the entire process or some certain stages of the construction project according to the contract and takes full liability for the quality, safety, duration and cost etc. of the contracted project.



Response Time and After-sales Services

If any failure due to a defect has occurred during the warranty period, our company has given the following response and promise: to respond within 12 hours and rush to the domestic scene within 72 hours. With a rigorous and efficient service architecture, diverse and flexible service and response means, Toncin is capable of providing response service up to 7* 24 hours to ensure that users can get help at any time during the warranty period.
