Home » Products » Automatic Packaging Equipment » Mini Stretch Wrapping Machine » Mini Barrel Wrapping Machine Mini Stretch Wrapping Machine Packing Machine

Mini Barrel Wrapping Machine Mini Stretch Wrapping Machine Packing Machine

KNT, this model is used for small size goods wrapping, top platen device ensure smooth and safe wrapping process. Which could be customized according to customer demand.
Quantity:
  • KNT
  • TONCIN

KNT, this model is used for small size goods wrapping, top platen device ensure smooth and safe wrapping process. Which could be customized according to customer demand.


Technical parameter:

Type KNT600FKNT1000F
Wrapping size600mm*600mm*(350-600)mm(L*W*H)1000mm*1000mm*(600-1000)mm(L*W*H)
Machine dimesion1400mm*520mm*2535mm
(L*W*H)
1500mm*520mm*2810mm
(L*W*H)
Power1.2kw/AC220V/50HZ1.2kw/AC220V/50HZturn
Turntable load(max)100kg100kg
Weight 180kg250kg
Wrapping efficiency 20-40 pallets/hour
Film carriagePre stretch ratio 300%, adjustable
Control systemPLC control, wrapping layer adjustable
Top platenPneumatic



Features(carton wrapping machine)
1.PLC Control

2.Easy to set parameters via panel as follwing:

Top/bottom wrap times,carriage up/dowm times.

3.Powered pre-stretch film carriage up to 250%.

4.Cycle pause capacity.

5.Film tension,turntable speed separate adjustment from control panel.

6.Separate auto-start/reset,pause&E/S buttons.

7.Minnimum maintenance.

8.Pneumatic top plate ensure packing clam and safety.
