Horizontal Wrapping Machine

DS600 machine applies on long ,square products which inner diameter<600mm(DS 400 applies on long , square products which inner diameter<400mm).widely used on plastic profile,aluminium profile,board,pipe, textiles, construction board ,steel industry etc,it works with many kinds of wrapping materials, like stretch film, composite paper, woven bags, EPÉE etc. .Elegant wrapping, anti-distant moisture, stable and safe, easy operation.

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button
  • DS1800

  • TONCIN

DS1800 Wrapping Machine

The DS1800 is designed for wrapping long and square products, making it an ideal choice for various industries including profiles, aluminum, boards, pipes, textiles, construction, and steel. It offers elegant wrapping with moisture resistance, stable and safe performance, and easy operation, ensuring it is your best choice for packaging needs.

DS1800

Product Specifications:

  • Model: DS1800

  • Ring Size: Φ1800mm

  • Speed: 15-25 rpm

  • Max Wrapping Size: 12001200mm (WH)

  • Wrapping Length: ≥2m

  • Wrapping Speed: 2-20 m/min

  • Power: 380V/50HZ/2.2KW

Customization options are available based on your specific requirements.


Product Details:

  1. Customizable Ring Size

    • The rotary ring size can be tailored to customer demands, accommodating the smallest and most slender cargo as well as bulk heavy items.

  2. Fully Automatic Packaging Technology

    • Features include automatic film clamping, goods detection, film feeding, and a pre-stretch film carriage with a photocell sensor to set the packing position. It offers a pre-stretch rate of up to 350%.

  3. Pneumatic Top Platen

    • Pneumatically driven pressing devices effectively secure products during wrapping.

  4. Flexible Conveyor Lines

    • Compatible with powered and non-powered transmission lines, drum conveyor lines, and belt conveyor lines.

  5. Special Holder Design

    • The holder ensures goods are wrapped successfully and securely.

  6. Operational Panel

    • Equipped with a PLC control and a touch screen user interface. The rotation and conveyor speeds are variable, and the overlapping width can be adjusted as needed.

This machine combines high functionality with user-friendly features, making it a valuable addition to any production line.
