The unique grouting of each filter chamber ensures synchronous feeding of all filter chambers, uniform force on the filter plate, short filling time of the slurry into the filter chamber, and significantly faster filtration speed than the fast opening filter press with central feeding.
(2) Fully automated operation
This equipment integrates functions such as filtration, cake washing, extrusion, air drying, automatic unloading, and automatic cleaning of filter cloth. It uses a PLC programmable controller and signal control devices set at various control points of the filter press to ensure safe and reliable automatic closed-loop operation of the filter press. It operates 100% automatically without manual intervention, reducing the labor intensity of workers.
(3) Low moisture content in filter cake
By using high-pressure diaphragm extrusion and high-pressure air blowing drying, the moisture content of the filter cake is significantly reduced.
(4) High output
The filter plates are placed horizontally, and each filter plate is individually and quickly fed, resulting in fast feeding and high output.
(5) Filter cloth regeneration
Equipped with an automatic cleaning device for filter cloth, both sides of the filter cloth are washed with clean water.
(6) Can adjust operating parameters at any time
The electric control cabinet adopts a touch screen to display real-time images and data of each operation action of the filter press, which can adjust the filter press process parameters for users at any time according to changes in on-site working conditions.
(7) The sealing pressure of the filter plate is high, and no slurry is sprayed
High pressure oil cylinder compression, automatic pressure maintenance, can ensure reliable sealing of the filter press under 1.6Mpa diaphragm pressing pressure.
(8) Environmental Protection
The filtrate and high-pressure air are discharged in the form of undercurrent, reducing pollution to the operating environment.
(9) Durable and long-lasting
The whole machine adopts a four column frame structure and all steel filter plates, making the equipment durable and long-lasting.
(10) Can save a lot of human resources
During normal production, there is no need for personnel to be on site or for one person to guard multiple vertical machines.
Principle
The long program control working mode of the vertical filter press has six processes: filtration: pumping into the material suspension; Primary diaphragm extrusion: extrusion to form a filter cake; Filter cake washing: clean water washing and filtering; Secondary diaphragm extrusion: re-extruding the filter cake; Filter cake blow drying: high-pressure air blow drying to take away a small amount of moisture; Filter cake discharge and filter cloth washing: the filter cake is dropped on both sides, the material is discharged, and the filter cloth is washed at the same time.
Service Support
Whole Technological Design
Toncin determines reasonable plans and selections by conducting more systematic laboratory tests, semi-industrialization tests and theoretical analysis calculations and adopting appropriate methods in light of the actual problems faced by customers. And it determines specific parameters through laboratory tests and semi-industrial tests.
Project Construction
Toncin can provide customers with integrated project services for its perfect project management system and experienced high-quality team and can also provide customers with its best services in achieving the ultimate project goal by carrying out the management work on the project quality, schedule, safety, cost, procurement, information files, organization and coordination etc. according to customer’s contractual documents. Toncin contracts the design, procurement, construction and trials etc. for the entire process or some certain stages of the construction project according to the contract and takes full liability for the quality, safety, duration and cost etc. of the contracted project.
Response Time and After-sales Services
If any failure due to a defect has occurred during the warranty period, our company has given the following response and promise: to respond within 12 hours and rush to the domestic scene within 72 hours. With a rigorous and efficient service architecture, diverse and flexible service and response means, Toncin is capable of providing response service up to 7* 24 hours to ensure that users can get help at any time during the warranty period.
