Tower/vertical Filter Press for Mining Industry in China
Tower/vertical press filter use air or water to form a huge pressure difference on both sides of filter cloth to achieve very efficient separation of solid and liquid.
HVPF vertical automatic press filter is the most advanced filter that the world has ever get. Vacuum has a limit, but Pressure not. HVPF vertical automatic press filter use air or water to form a huge pressure difference on both sides of filter cloth to achieve very efficient separation of solid and liquid. As filter plate is closed, slurry is pumped into filter chamber through slurry pipes. Part of filtrate then enter the filtrate chamber through filter cloth because of gravity. Then high pressure water force rubber diaphragm to extrude filtrate from filter cake. When these process is finished, the driver run filter clothes and filter cakes is discharged from both sides of filter cloth.
Product Application
HVPF vertical automatic press filter can be applied in mining, metallurgy, chemical industry, pharmacy and food industries. It is a kind of high capacity, energy-saving, automatic solid-liquid separation machine.
Supply Range and Requirements on Local Installation
(1) It consists of host, hydraulic station, water station, cleaning system and control system.
(2) This machine must be installed on solid flat reinforced concrete, or steel rack. Consult foundation size and related dimension to installation sketch map and foundation chart. The depth of groundwork is determined by customers according to real conditions. Host should be suspended by professional technicians, avoid the equipment from impacting or scratching. Utilize grad enter to adjust the host during installation, then install other equipments during fastening the host.
(3) Air supply: granule less than 5 um, pressure 0.5-0.6MPa, Air Volume: take assemble chart as reference
(4) Water supply: max. solid contents 5ppm, solid granule less than 50um, pressure 3.5-6bar, take assemble chart as reference for supply volume
(5)Power supply: 3 phase/380V±5%, single phase/220V±5%,50Hz
(6)Working Environment: working environment requirements for this machine , not freeze.
Product Specifications
Model
Filtrating Area(m2)
Overall Dimension
m (L×W×H)
Filtrating Plate Quantity
Volume(m3) (H=45mm)
Weight
(T)
Hydraulic power
(KW)
Filter plate specification
(mm)
Width of filter cloth
HVPF-1
1
2.5×1.5×2.0
2
0.05
8
7.5
1000*550
0.7
HVPF-2
2
2.5×1.5×2.2
4
0.09
9
7.5
HVPF-3
3
3.5×2.5×2.2
2
0.16
14
11
1750*900
1.05
HVPF-4
4
3.5×2.5×2.3
4
0.27
15
11
HVPF-9
9
3.5×2.5×2.5
6
0.41
16
11
HVPF-12
12
3.5×2.5×2.7
8
0.54
17
11
HVPF-15
15
3.5×2.5×2.9
10
0.68
18
11
HVPF-18
18
3.5×2.5×3.1
12
0.81
19
11
HVPF-21
21
3.5×2.5×3.3
14
0.95
21
11
HVPF-24
24
3.5×2.5×3.4
16
1.08
22
11
HVPF-27
27
3.5×2.5×3.6
18
1.22
23
11
HVPF-15
15
5.1×3.7×3.3
6
0.68
37
22
2500*1020
1.15
HVPF-20
20
5.1×3.7×3.6
8
0.9
39
22
HVPF-25
25
5.1×3.7×3.9
10
1.13
42
22
HVPF-30
30
5.1×3.7×4.2
12
1.35
43
22
HVPF-35
35
5.1×3.7×4.5
14
1.58
44
22
HVPF-40
40
5.1×3.7×4.8
16
1.8
45
22
HVPF-45
45
5.1×3.7×5.1
18
2.03
46
22
HVPF-50
50
5.1×3.7×5.4
20
2.25
48
22
HVPF-60
60
6.9×4.5×5.4
10
2.7
97
37
4010*1500
1.7
HVPF-72
72
6.9×4.5×5.8
12
3.24
100
37
HVPF-84
84
6.9×4.5×6.2
14
3.78
104
37
HVPF-96
96
6.9×4.5×6.5
16
4.32
110
37
HVPF-108
108
6.9×4.5×6.9
18
4.86
112
37
HVPF-120
120
6.9×4.5×7.2
20
5.4
118
37
HVPF-132
132
6.9×4.5×7.6
22
5.94
120
37
HVPF-144
144
6.9×4.5×7.9
24
6.48
123
37
HVPF-156
156
6.9×4.5×8.3
26
7.02
126
37
HVPF-168
168
6.9×4.5×8.6
28
7.56
130
37
HVPF-144
144
9.2×5.5×6.8
18
6.48
142
67
6020*1500
1.7
HVPF-162
162
9.2×5.5×7.2
18
7.29
147
67
HVPF-180
180
9.2×5.5×7.5
20
8.1
150
67
HVPF-198
198
9.2×5.5×7.8
22
8.91
160
67
HVPF-216
216
9.2×5.5×8.2
24
9.72
166
67
HVPF-234
234
9.2×5.5×8.5
26
10.53
172
67
HVPF-252
252
9.2×5.5×8.8
28
11.34
180
67
HVPF-270
270
9.2×5.5×9.2
30
12.15
190
67
Working Process
(1) Filtering stage: when the filter plate closed, the slurry is pumped into filter chamber through slurry pipe. The filtrate enter into the filtrate chamber through filter cloth, and get into filtrate manifold through filtrate tube, meanwhile, the filter cake is formed in the filter chamber.
(2) Extrusion: the high pressure water enters into membrane through the tube and make the membrane extrudes towards filter cake to make the filtrate of the filter cake extrude out.
(3) Cake washing: the washing water is pumped into filter chamber by slurry pipe, after washing the cake and through cloth flow into the discharge pipes.
(4) Air drying: the air flow with water go through the filter cake, which can reduce the moisture of filter cake to the maximum and empty the filtrate chamber at the same time.
(5)Filter cake discharge: when the drying process finished, the driving parts drive the filter cloth to run and the filter cake discharges from both sides of filter cloth.
Main Features
Guided Operation
The filter plate structure incorporates a guide device to ensure smooth and stable operation.
Fully Automated Process
The system enables continuous, automated operation, including filtration, extrusion, washing, drying, discharging, and filter cloth regeneration—all without manual intervention.
High-Pressure Filtration (Up to 2.0 MPa)
Effectively processes viscous fine materials and achieves low-moisture filter cakes with superior efficiency.
Safety-First Design
The hydraulic pressure system ensures secure plate locking under all pressure conditions.
Critical components (nozzles, diaphragms) undergo rigorous design and inspection to guarantee safety during high-pressure water injection.
Intelligent Control System
Equipped with PLC + touch screen + automatic valves for seamless operation, minimizing labor requirements.
Space-Saving Structure
Compact design reduces footprint while maintaining high performance.
Product Details
Service Support
Whole Technological Design
Toncin develops optimized solutions through systematic laboratory testing, semi-industrial trials, and theoretical analysis, tailored to address clients' specific challenges. Key parameters are validated via rigorous experimental and pilot-scale testing.
Project Construction
Leveraging a robust project management system and a seasoned expert team, Toncin delivers end-to-end project services. We ensure exceptional outcomes by overseeing quality, schedule, safety, cost control, procurement, documentation, and cross-functional coordination—all aligned with contractual requirements.
Depending on the project scope, Toncin manages design, procurement, construction, and commissioning for either full-project or phase-specific delivery, assuming full accountability for quality, safety, timelines, and budget compliance.
Warranty Service Commitment
Should any failure occur due to a defect during the warranty period, Toncin guarantees the following:
12-hour response to all service requests.
On-site support dispatched within 72 hours for domestic cases.
Backed by a rigorous and efficient service framework, Toncin delivers 24/7 support through flexible, multi-channel solutions, ensuring prompt assistance throughout the warranty period.
